The S4D450-AO14-02 from EBM-Papst is a robust axial fan with a protective grille, designed for demanding industrial ventilation applications. The fan is supplied in size 538 × 538 × 214 mm and is powered by a three-phase AC motor (M4D094-HA) for 400/480 V AC at 50/60 Hz. With an IP54 protection rating and ball bearings, it is built for long and reliable operation.
The fan is ideal for integration into units and duct systems where high airflow and robust construction are required. The sickle-shaped steel blades with a PP plastic surface contribute to efficient airflow control and low noise levels.
- Airflow: up to approx. 7,080 m³/h (free air, 400 V, 50 Hz, delta connection)
- Power: 480 W, rated current 0.98 A
- Sound pressure level: 65 dB(A)
- Protection class IP54
- Insulation class F, operating mode S1
- Thermal overload protection (TOP) with basic insulation
- Ambient temperature: −40 °C to +65 °C
- Weight: 9.8 kg
At Reserv, you'll find original EBM-Papst parts stocked by our wholesaler. This means short delivery times and reliable quality — exactly what you need when downtime is not an option. See the datasheet on the product page for complete technical information.
Technical specifications
Datasheet (PDF) - download| Product attribute | Value |
|---|---|
| Airflow at 0 Pa | 4535 m³/h |
| Speed | 1060/1110/1240/1360/1510/1600 rpm |
| Power | 480W |
| Frequency | 50/60 Hz |
| Voltage | 400/480 V AC VAC |
| Motor frame | The fans are supplied with a protection guard for short nozzles and are intended for installation in air handling units or duct systems. The standard installation position is shaft horizontal or rotor downwards; rotor upwards is possible on request. Condensate drainage holes are located on the rotor side. The tightening torque for mounting is 1.5 ± 0.2 Nm. The unit weighs 9.8 kg and has a size designation of 450 mm. |
| Casing | Steel protective grille coated with black plastic (RAL9005), PP plastic terminal block |
| Impeller | The fan impeller has 5 sickle-shaped blades of the S-series type, made from pressed sheet steel without surface treatment and sprayed with PP plastic. The rotor surface is painted black, and the airflow direction is marked as 'A'. The fan impeller is designed for an axial fan with a diameter of 450 mm and provides an airflow of up to approximately 7080 m³/h in free air (400 V, 50 Hz, delta connection). The protective grille is made of steel coated with black plastic (RAL9005) and is adapted for short nozzles. |
| Bearing type | ball bearing |
| IP class | IP54 |
| Motor protection | Thermal overload protection (TOP) with basic insulation |
| Motor code | M4D094-HA |
| Rotation direction | clockwise, looking towards the rotor |
| Motor type | The motor is a three-phase AC motor, type M4D094-HA, with insulation class F and operating mode S1. It is equipped with thermal overload protection (TOP) with basic insulation and belongs to protection class I, provided that the customer connects protective earth. The motor can withstand ambient temperatures between -40 °C and +65 °C (depending on frequency and connection) and has a maximum transport/storage temperature of +80 °C. The humidity protection class is H2, and the motor complies with standard EN60034-1 and is CE marked with CCC and EAC approvals. |
