The 712F from EBM-Papst is a compact DC axial fan with a wall ring, designed for reliable cooling and ventilation in confined spaces. Measuring 70 × 70 × 15 mm, the fan is powered by 12 V DC with a voltage range of 8–13.8 V. It is ideal for electronic equipment, industrial automation, and appliance cooling where space is limited.
Thanks to its optional mounting position and 310 mm long connecting cable, the 712F is easy to integrate into existing designs. The motor features built-in reverse polarity protection and automatic restart in case of a locked rotor, providing extra operational reliability.
- Airflow: 43 m³/h
- Maximum static pressure: 72 Pa
- Speed: 5,300 rpm
- Power: 1.7 W
- Sound pressure level: 38 dB(A)
- Voltage range: 8–13.8 V DC
- Bearing type: sleeve bearing
- Housing: plastic, 70 × 70 × 15 mm
At Reserv, you'll find original EBM-Papst parts stocked by wholesalers, ensuring fast delivery and the right quality directly to you. See the datasheet on the product page for full technical information.
