The 8315100107 from EBM-Papst is a compact axial fan with a wall ring for direct current, from the S-Panther series. The fan measures 80 × 80 × 32 mm and is designed for reliable cooling in electronics, telecommunications, and industry. With a wide voltage range of 12–28 V DC, it fits into a variety of applications.
The S-Panther series is a popular choice for OEM designers and maintenance technicians who require quiet, efficient, and reliable cooling in confined spaces.
- Airflow: 78 m³/h at free flow
- Maximum static pressure: 116 Pa
- Rated voltage: 24 V DC (range 12–28 V)
- Rotational speed: 3,370 rpm
- Noise level: 43 dB(A) at 1 meter distance
- Bearing type: Ball bearing for long lifespan
- Protection class: IPX4 (not certified)
- Built-in reverse polarity protection and automatic restart upon locked rotor
At Reserv, EBM-Papst products are stocked by our wholesaler, which means fast delivery of original parts directly to you. You can be sure that you get the right component – every time. See the datasheet on the product page for complete technical information.
Technical specifications
Datasheet (PDF) - download| Product attribute | Value |
|---|---|
| Airflow at 0 Pa | 78 m³/h |
| Speed | 3370 rpm |
| Power | 1.6 W |
| Voltage | 24V DC VAC |
| Motor frame | The fan has a square plastic casing with dimensions of 80 × 80 × 32 mm and a weight of 0.1 kg. Mounting is via mounting flanges with ISO 4762 M4 screws, degreased and without washers. The maximum tightening torque during assembly is 100 Ncm for all corners. The mounting position for the shaft can be in any orientation. |
| Casing | plastic, square |
| Impeller | The impeller is made of plastic and designed for axial airflow with air discharge over the struts. At a nominal speed of 3370 rpm, the impeller delivers a maximum free air flow of 78 m³/h and a maximum static pressure of 116 Pa. The direction of rotation is counter-clockwise when viewed from the rotor side. The sound pressure level at free air flow is 43 dB(A) measured at a distance of 1 meter. |
| Bearing type | ball bearing |
| IP class | IPX4 (not certified) |
| Motor protection | automatic restart on locked rotor |
| Motor code | 8314NMU-00107 |
| Rotation direction | counter-clockwise |
| Motor type | The motor is a DC motor with a nominal voltage of 24 V and a voltage range of 12–28 V. Power consumption at free airflow is 1.6 W with a current consumption of 66 mA. The motor has built-in reverse polarity protection via a rectifier diode and automatic restart in case of a locked rotor. The motor protection class is III and the insulation meets the requirements of DIN EN 62368. |
