The 9292506113 from EBM-Papst is a compact DC axial fan with a wall ring, designed for reliable cooling and ventilation in electronics and industrial applications. Measuring 80 × 80 × 25 mm, the fan is powered by a 24 V DC motor with a wide voltage range of 18–28 V. With an airflow of 65 m³/h and a sound level of just 32 dB(A), it delivers efficient performance with minimal disturbance.
The fan is ideal for tight spaces where flexible mounting and low noise are important. The optional mounting position for the shaft makes it easy to integrate into existing designs.
- Airflow: 65 m³/h
- Voltage: 24 V DC (18–28 V)
- Power consumption: 2 W
- Speed: 3,100 rpm
- Sound pressure level: 32 dB(A)
- Maximum static pressure: 43 Pa
- Motor protection: automatic restart on locked rotor and reverse polarity protection
- Housing: square plastic, 80 × 80 × 25.4 mm
Reserv keeps genuine EBM-Papst parts in stock and delivers them quickly to you. You can rest assured that you will receive an authentic product with full quality — every time. See the datasheet on the product page for complete technical information.
