The 9292910145 from EBM-Papst is a compact S-Panther type axial fan with a wall ring, in the 80 × 80 × 32 mm format. It is powered by a 24 V DC motor with PWM control and delivers up to 115 m³/h at 7,600 rpm. The fan is ideal for dense electronic installations and cooling applications where high performance is required in a small form factor.
With built-in restart protection for locked rotor and reverse polarity protection, it is designed for operational reliability in industrial and commercial environments. The 25 kHz PWM frequency ensures smooth and quiet control.
- Voltage: 24 V DC (range 18–26.4 V)
- Airflow: up to 115 m³/h
- Maximum static pressure: 220 Pa
- Speed: 7,600 rpm
- Noise level: 52 dB(A)
- Bearing type: ball bearing
- PWM control: 21–28 kHz (typical 25 kHz)
- Optional mounting position, connection via 310 mm cable
At Reserv, you get original parts from EBM-Papst, stocked by wholesalers for fast delivery. You can be confident that you receive the correct component – every time. See the datasheet on the product page for complete technical information.
Technical specifications
Datasheet (PDF) - download| Product attribute | Value |
|---|---|
| Airflow at 0 Pa | 115 m³/h |
| Speed | 7,600 rpm |
| Power | 8.9 W |
| Voltage | 24V DC VAC |
| Motor frame | The fan is of the axial panel type, measuring 80 × 80 × 32 mm and weighing 0.1 kg. The housing is made of plastic. Mounting is done with ISO 4762 M4 screws without additional support or washer, with a maximum tightening torque of 100 Ncm in all mounting corners. The shaft can be mounted in any position. |
| Casing | plastic, square |
| Impeller | The fan impeller is made of plastic and rotates counter-clockwise when viewed from the rotor side. Airflow is directed out over the struts. At 7,600 rpm and free airflow, the fan delivers up to 115 m³/h with a maximum static pressure of 220 Pa. The optimal operating point is 83 m³/h at 85 Pa. |
| Bearing type | ball bearing |
| Motor code | 8314 N/2H3P |
| Rotation direction | counter-clockwise |
| Motor type | The motor is a DC motor with a rated voltage of 24 V and a voltage range of 18–26.4 V. With free airflow and 100% PWM, the motor consumes 8.9 W with a current consumption of 370 mA. The motor has built-in restart protection in case of locked rotor and reverse polarity protection via a rectifier diode. Control is performed via a PWM signal with a frequency of 21–28 kHz (typically 25 kHz). |
