The 9692910208 from EBM-Papst is a powerful DC axial fan with a wall ring in a compact 80 × 80 × 38 mm format. The fan is equipped with a high-performance DC motor with PWM speed control and delivers impressive performance in a small package. It is ideal for demanding applications where high air capacity and robust construction are crucial.
With a maximum airflow of 220 m³/h and a static pressure of up to 710 Pa, this fan is ideal for cooling in industrial electronics, server equipment, and dense cabinets. The optional mounting position provides great flexibility during installation.
- Airflow: 220 m³/h (max), optimal operating point 135 m³/h at 330 Pa
- Voltage: 24 V DC (operating range 12–27.6 V)
- Speed: 14,000 rpm
- Power: 39 W
- PWM speed control (1–5 kHz)
- Lifespan up to 50,000 hours (L10) at 40 °C
- Protection class IPX4 with ball bearings
- Built-in reverse polarity protection and automatic restart in case of locked rotor
At Reserv, we stock genuine EBM-Papst parts for fast delivery directly to your business. You can be confident that you are getting authentic components with a full quality guarantee. See the datasheet on the product page for complete technical information.
Technical specifications
Datasheet (PDF) - download| Product attribute | Value |
|---|---|
| Airflow at 0 Pa | 220 m³/h |
| Speed | 14,000 rpm |
| Power | 39 W |
| Voltage | 24V DC VAC |
| Motor frame | The fan has a plastic housing measuring 80 × 80 × 38 mm and weighs 250 grams. Mounting holes are designed for M4 screws (ISO 4762) without additional support or washers. The mounting position for the shaft is optional. Maximum tightening torque varies depending on the mounting corner: 50 Ncm at the cable outlet corner and 110 Ncm at the other corners. |
| Casing | plastic, square |
| Impeller | The impeller is made of plastic and rotates counter-clockwise when viewed from the rotor side. Airflow is directed over the struts (air outlet over struts). At full speed (14,000 rpm), the impeller delivers a maximum free air flow of 220 m³/h and a maximum static pressure of 710 Pa. The optimal operating point is 135 m³/h at 330 Pa. |
| Bearing type | ball bearing |
| IP class | IPX4 |
| Motor protection | automatic restart at locked rotor |
| Motor code | 8214 J/2H4PU-208 |
| Rotation direction | anticlockwise |
| Motor type | The motor is a DC motor with electronic speed control via PWM signal (1–5 kHz). The nominal voltage is 24 V DC with a permissible voltage range of 12–27.6 V. The motor has built-in reverse polarity protection via a rectifier diode and automatic restart in case of a locked rotor. The service life is up to 50,000 hours (L10) at 40 °C ambient temperature. |
