The 9694320202 from EBM-Papst is a compact DC axial fan with a wall ring, designed for demanding cooling and ventilation needs. With an impressive airflow of 340 m³/h and a maximum static pressure of 240 Pa, it delivers reliable performance in a compact 127 × 127 × 38 mm housing. The fan is ideal for electronics cabinets, industrial machinery, and other applications where efficient air circulation is crucial.
Thanks to its wide voltage range of 9–15 V DC and optional mounting position, it is easy to integrate into existing systems. The motor features built-in reverse polarity protection and automatic restart upon locked rotor, ensuring high operational reliability.
- Airflow: up to 340 m³/h
- Voltage: 12 V DC (9–15 V allowed)
- Speed: 4,900 rpm
- Power: 19 W
- Sound pressure: 58 dB(A)
- Bearing type: ball bearings for long lifespan
- Motor protection: automatic restart and internal 5 A fuse
- Connection: 310 mm cable
At Reserv, EBM-Papst original parts are stocked by established wholesalers, ensuring fast delivery and genuine quality. Choose Reserv for secure and easy ordering of spare parts. See the datasheet on the product page for complete technical information.
Technical specifications
Datasheet (PDF) - download| Product attribute | Value |
|---|---|
| Airflow at 0 Pa | 340 m³/h |
| Speed | 4900 rpm |
| Power | 19 W |
| Voltage | 12 V DC VAC |
| Motor frame | The fan has a square plastic housing measuring 127 × 127 × 38 mm and weighs 315 g. Mounting is done with ISO 4762 M4 screws without washers. Maximum tightening torque varies depending on the mounting corner: 10 Ncm at the cable outlet corner and 60 Ncm at the other corners. |
| Casing | plastic, square |
| Impeller | The impeller is made of plastic and has a diameter of 127 mm. It rotates counter-clockwise when viewed from the rotor side and conveys air over the struts. At free airflow, a maximum airflow of 340 m³/h and a maximum static pressure of 240 Pa are achieved at 4900 rpm. |
| Bearing type | ball bearing |
| Motor protection | automatic restart on locked rotor, internal fuse 5 A |
| Motor code | 5212 NHH |
| Rotation direction | counter-clockwise |
| Motor type | The motor is a DC motor with speed control and reverse polarity protection via a rectifier diode. It has automatic restart in case of locked rotor and an internal fuse (Littelfuse NANO2, 5 A). Nominal voltage is 12 V DC with an allowed voltage range of 9–15 V. Current consumption with free airflow is 1580 mA at nominal voltage. |
