The 9694360192 from EBM-Papst is a compact axial fan with a wall ring for direct current, designed for demanding ventilation applications. With an airflow of 170 m³/h and a maximum static pressure of 78 Pa, it delivers efficient air circulation in a small form factor. The fan is ideal for electrical cabinets, cooling systems, and industrial equipment where reliable and quiet operation is a requirement.
Thanks to its wide voltage range of 18–28 V DC and support for an external NTC temperature sensor, the fan is well-suited for systems with variable cooling requirements. Approvals from CE, UL, VDE, and CSA make it a safe choice for international applications.
- Airflow: 170 m³/h at free flow
- Voltage: 24 V DC (range 18–28 V)
- Speed: 2800 rpm, clockwise rotation
- Sound pressure: 45 dB(A)
- Power: 4.8 W | Rated current: 200 mA
- Ball bearings for long service life
- Built-in protection against reverse polarity and automatic restart in case of locked rotor
- Dimensions: 119 × 119 × 32 mm | Weight: 0.22 kg
Reserv stocks original EBM-Papst parts and delivers quickly to those who don't have time to wait. With us, you get genuine components with full specifications — simple and reliable. See the datasheet on the product page for complete technical information.
Technical specifications
Datasheet (PDF) - download| Product attribute | Value |
|---|---|
| Airflow at 0 Pa | 170 m³/h |
| Speed | 2800 rpm |
| Power | 4.8 W |
| Voltage | 24V DC VAC |
| Motor frame | The fan is mounted with M4 screws (ISO 4762) without washers or additional reinforcement. The maximum tightening torque during assembly is 20 Ncm in all corners. The mounting position for the shaft can be arbitrary. The fan's dimensions are 119 × 119 × 32 mm and its weight is 0.22 kg. |
| Casing | plastic, square |
| Impeller | The fan impeller is made of plastic and mounted in a square plastic frame with dimensions of 119 × 119 × 32 mm. The airflow is directed over the struts (air outlet over struts). At free airflow and 2800 rpm, the fan delivers up to 170 m³/h with a maximum static pressure of 78 Pa. |
| Bearing type | ball bearing |
| Motor code | 4314/17T-192 |
| Rotation direction | clockwise |
| Motor type | The motor is a DC motor with electronic speed control via an external NTC temperature sensor. It has built-in reverse polarity protection via a rectifier diode and automatic restart in case of locked rotor. The nominal voltage is 24 V DC with a voltage range of 18–28 V. The motor has protection class III and is approved according to CE, UL, VDE, and CSA. |
